Green Pin Polar® - Bow Shackle with Fixed Nut Safety Pin
The Green Pin Polar® Bow Shackle is a bow shackle with a safety bolt and fixed nut that has been optimized for use in low temperatures. The shackle can be used in extreme climatic conditions, down to -60°C (-76°F).
The shackle is the perfect choice when the load is dynamic or exposed to extreme vibrations because of its triple safety (split pin, safety bolt and fixed nut).
The fixed nut of the Green Pin Polar® Bow Shackle is drilled through both the shackle nut and pin and is firmly attached to the pin head with bolts and Nord-Lock® washers.
Long-term durability is assured due to the galvanization of the Green Pin Polar® Bow Shackle.
The shackle conforms to a wide range of certifications from class societies such as DNV GL. T
he Green Pin Polar® Bow Shackle is suitable for both one-leg and multi-leg systems and is available in a range with a working load limit from 2T up to 85T.
All Individual items over 30kg in weight are subject to mini pallet rates which are not calculated or specified during checkout, additional charges may be required prior to dispatch.
Green Pin Polar® - Bow Shackle with Fixed Nut Safety Pin
Details
- Grade 8 alloy steel body and pin, quenched and tempered
- Hot dipped galvanized finish
- Minimum breaking load is 7 times the W.L.L.
- Temperature range -60ºC up to +200ºC
- Extra AISI 316 securing bolt drilled through the nut and shackle pin
- Complete with Nord-Lock® wedge-locking washers that lock when subjected to extreme vibration or dynamic loads
- Marked with CE, W.L.L, manufacturers ID, size and traceability code
- Certification available
